רסיבר ‏5.1 ‏ערוצים Pioneer VSXS520 פיוניר

רסיבר 5.1 דק מאוד (6.5 ס”מ)

80W לכל ערוץ . 4 כניסות HDMI 2.0 תקן HDCP 2.2

USB קדמי +BLUETOOTH

3D . 4K . ARC. PASS THROUGH עד 4K60P 4;4;4

הזרמת מוסיקה דרך TUNE IN . GOOGLE CAST .TIDAL ועוד

כניסה פונו . ממיר DAC משופר . שלט חדש

עם חיבור רשת WIFI .שליטה מלאה מטלפון באמצעות אפליקציה

אחריות:24 חודשים ( יבואן רשמי)

• Slim 2.76” Low-profile Design
• Built in Bluetooth® and WiFi®
• Ultra HD Pass-through (4K UltraHD 60P/4:4:4) with HDCP 2.2
• 80 W/ch (4 ohms, 1 kHz, THD 1.0 %, 1ch Driven FTC)
• 50 W/ch (4 ohms, 1 kHz, THD 1.0 %, 2ch Driven FTC)

• Amplifier DesignClass D
• Channels6
• Power Output: Watts per Channel (1 kHz, 1.0%THD@4ohm, 2ch driven FTC)50 W
• Power Output: Watts per Channel (1 kHz, 1.0%THD@4ohm, 1ch driven FTC)80 W
• Estimated Power Consumption/Network Standby off60 W / 0.2 W

HANDHELD AND INTERNET

• AirPlayYes
• HTC Connect–
• Made for iPhone and iPodAirPlay Only
• iOS/Android Remote Control APPPioneer Remote App
• TIDAL Music Streaming Service ReadyYes
• Pandora Internet RadioYes
• Internet RadioTuneIn Radio

DECODERS & FORMATS

• Digital Core DSP EngineCirrus Logic (Quad Core) x1
• iPod Digital Audio–
• Music File PlaybackMP3, WMA, AAC, Apple Lossless*, WAV*, FLAC*, AIFF, DSD via USB and Network (*up to 192kHz/24-bit),
• High-Definition Copy Protection (HDCP)2.2
• Dolby Atmos3.1.2ch
• Dolby TrueHDYes
• Dolby Digital PlusYes
• DTS:X–
• DTS-HD Master AudioYes
• DTS Neural:X–
• DTS Neo:X–
• HDMI SACD TransferMulti-Channel

SOUNDFIELD CALIBRATION

• Phase ControlYes
• MCACCYes
• MCACC Memory1
• Standing Wave Control–
• EQ Bands9-Band
• Symmetric EQYes
• X-CurveYes
• Distance Adjustment0.1 feet
• Polarity Check–
• Auto Subwoofer CrossoverYes

LISTENING MODES

• Auto SurroundYes
• Stream DirectYes (Direct, Pure Direct)
• Advanced Surround12
• Wide Surround–
• Front Stage Surround AdvanceYes
• Headphone Surround–
• Virtual Speakers–

AUDIO FEATURES

• Dialog Enhancement–
• Advanced Sound RetrieverYes
• DSD Music File2ch(2.8MHz / 5.6MHz)
• Sound Retriever AIR–
• Digital Noise Reduction–
• Tone ControlMulti
• Sound Delay (Lip Sync)500 ms @ 48k/ 400 ms @ 96k/ 200 ms @ 192k
• Speaker A/BYes
• Bi-Amp–

VIDEO PROCESSING

• 4K Ultra HD Pass-ThroughYes
• 4K Ultra HD Video ScalerYes (1080p to 4K)
• 3-D ReadyYes
• Audio Return ChannelYes
• HDMI Standby ThroughYes with Input Switch / Last Memory
• HDMI 36-bit Deep ColorYes
• HDMI x.v. ColorYes
• Video Processor–
• Video Converter to HDMI–
• HDMI to HDMI Video Scaler4K Ultra HD (for 1080p)
• Component Video Scaler–
• Composite Video Scaler–
• Pure Cinema I/P Converter–
• Advanced Video Adjustment–
• 3D Noise Reduction–
• Super ResolutionYes

CONNECTIVITY

• HDMI Input / Output4 in (4 Rear) /1 out
• MHL 2–
• Wi-Fi Built-InYes (5GHz/2.4GHz)
• Bluetooth Built-InYes (Version: 4.1, Profile: A2DP/AVRCP, Codec: SBC/AAC)
• Wireless Adapter Port–
• Bluetooth Adapter Port–
• Component Video Input / Output–
• Composite A/V Input / Output–
• iPhone / iPod / USB Memory InputUSB Memory
• USB TerminalFront USB
• Ethernet InputYes
• Analog Audio Inputs / Output–
• Digital Audio Inputs / Output2 In (Optical 1, Coaxial 1)
• Pre-Amp Output0.1 Ch
• Headphone OutputYes
• Front A/V InputsUSB
• AM/FM Presets40 (FM only)

INSTALLATION

• On-Screen DisplayGUI with System/Network Setup Menu
• Auto Power DownYes
• Multi-Room and Source OutputYes (with future firmware update)
• IR Serial Remote In/Out–
• Multi-Zone On-Screen Display–
• FL DimmerYes
• Function RenameYes
• RemoteYes
• Sleep TimerYes
• Versatile Speaker Configuration(FRONT, CENTER, SURROUND, SUBWOOFER)

DIMENSIONS

• W x H x D (inches)17.12 x 2.75 x 12.81
• Weight8.8 lbs
