• Amplifier DesignDiscrete Direct Energy
• Channels5.1
• Power Output: Watts per Channel (20Hz-20kHz,.08%THD@8ohm 2ch Driven)80 Watts
• Power Output: Watts per Channel (1kHz,1%THD@6ohm 1ch Driven)140 Watts
• Estimated Power Consumption/Network Standby off210 W/0.45 W (standby)

HANDHELD AND INTERNET

• AirPlay–
• HTC Connect–
• Made for iPhone and iPod–
• iOS/Android Remote Control APP–
• TIDAL Music Streaming Service Ready–
• Streaming Audio From PC/Network–
• Pandora Internet Radio–
• Internet Radio–

DECODERS & FORMATS

• Digital Core DSP EngineDigital Core Engine with Texas Instruments Aureus DSP
• Audio DACs192K/24Bit
• Audio Processing–
• iPod Digital Audio–
• Music File Playback48kHz / 16-Bit MP3, WMA, ACC Via USB
• High-Definition Copy Protection (HDCP)2.2
• Dolby Atmos–
• Dolby TrueHDYes
• Dolby Digital PlusYes
• DTS:X–
• DTS-HD Master AudioYes
• DTS Neural:X–
• DTS Neo:X–
• HDMI SACD Transfer2 Channel

SOUNDFIELD CALIBRATION

• Phase ControlYes
• MCACC–
• MCACC Memory–
• Standing Wave Control–
• EQ Bands–
• Symmetric EQ–
• X-Curve–
• Distance Adjustment0.1 feet
• Polarity Check–
• Auto Subwoofer Crossover–

LISTENING MODES

• Auto SurroundYes
• Stream DirectYes (Direct, Pure Direct)
• Advanced Surround10+1
• Wide Surround–
• Front Stage Surround Advance–
• Headphone Surround–
• Virtual Speakers–

AUDIO FEATURES

• Dialog Enhancement–
• Advanced Sound RetrieverYes (2ch)
• DSD Music File–
• Sound Retriever AIR–
• Digital Noise Reduction–
• Tone Control2 Channel
• Sound Delay (Lip Sync)Yes (500ms)
• Speaker A/B–
• Bi-Amp–

VIDEO PROCESSING

• 4K Ultra HD Pass-ThroughYes
• 4K Ultra HD Video Scaler–
• 3-D ReadyYes
• Audio Return ChannelYes
• HDMI Standby ThroughYes with Input Switch / Last Memory
• HDMI 36-bit Deep ColorYes
• HDMI x.v. ColorYes
• Video Processor–
• Video Converter to HDMI–
• HDMI to HDMI Video Scaler–
• Component Video Scaler–
• Composite Video Scaler–
• Pure Cinema I/P Converter–
• Advanced Video Adjustment–
• 3D Noise Reduction–
• Super Resolution–

CONNECTIVITY

• HDMI Input / Output4 In (Rear) / 1 Out
• MHL 2–
• Wi-Fi Built-In–
• Bluetooth Built-InYes
• Wireless Adapter Port–
• Bluetooth Adapter Port–
• Component Video Input / Output–
• Composite A/V Input / Output2 In (Coaxial x 1, Optical x 1)
• iPhone / iPod / USB Memory Input–
• USB TerminalFront USB
• Ethernet Input–
• Analog Audio Inputs / Output3 In
• Digital Audio Inputs / Output2 In
• Pre-Amp Output.1 ch (SW)
• Headphone OutputYes
• Front A/V InputsUSB (Audio Only)
• AM/FM Presets30

INSTALLATION

• On-Screen DisplayHDMI Only
• Auto Power DownYes
• Multi-Room and Source Output–
• IR Serial Remote In/Out–
• Multi-Zone On-Screen Display–
• FL DimmerYes
• Function Rename–
• RemoteYes
• Sleep Timer30, 60, 90 min.

CONSTRUCTION

• Front PanelBrushed
• Speaker Terminals2 large + 3 clip

WARRANTY

• Warranty1 Years Parts & Labor

DIMENSIONS

• W x H x D (inches)
  Wi-Fi Antenna’s Up–
• W x H x D (inches)17.1 x 6.6 x 12.6
• Weight17.6 lbs
